Reliant Kitten Pro-Street

Les Reliant sont très connu en Angleterre où elles sont très populaires surtout leur version à 3 roues qui pullulent encore de nos jours. Oui les anglais sont bizarres!!! Certains de ces anglais sont encore plus bizarre que la moyenne et décident de s’acharner sur une pauvre Reliant Kitten 4 roues en faisant d’elle une version Pro-Street!!! Bah oui encore une caisse pas chère avec un V8 Rover 3.5 litres qui arrache tout!!! Là y a quand même du bout de fait. La carrosserie est refaite en fibre, le châssis tubulaire complet et donc un V8. Rien a faire de plus pour bien délirer dans la rue et ne pas être ridicule sur les pistes de drags. Car avec son poids plume la petite Reliant abat le 400DA en 12.81 sec et a une top speed de 130 mph (environ 209km/h). Pas mal pour un pot de yaourt!!! Alors qui pour nous faire une R5, une Fiesta MK1 ou même une Panda aussi brutale que cette Reliant???

En prime je vous met des photos (petites désolé) de la fabrication, les specs et une vidéo pour vous prouver que ça marche fort!!!



Car ………………Reliant Kitten DL saloon. (The Kitten is the factory 4 wheel version of the 3 wheel Robin). Body is fibreglass.

Engine ………….3528cc Rover V8 from a SD1, ARP big end bolts, ARP main stud kit (replacing stock bolts), reground crank, align honed mains, Crane cam and lifters, Cloyes timing chain, K+N bronze valve guides machined to take Crane teflon seals, double valve springs, 3 angle valve seats, home ported heads, heads skimmed.

Gearbox ……….Borg Warner type 66 3 speed automatic, modified torque converter to give higher stall speed.

Chassis ………..Space frame 1 1/2″ x 1 1/2″ x 14 SWG square base with 1 1/2″ x 14 SWG round upper, bracing in smaller sizes. Welding with TIG.

Rear Axle …….Volvo 245 narrowed to 40″ flange to flange. 4.1 : 1 ratio.

Suspension …..Rear.. Spherically jointed adjustable 4 link. Spax coil overs, 110 lb/inch springs.. Front.. Shortened Ford struts. Spherically jointed arms. 130 lb/inch springs. 6 degree castor, -1 degree camber.

Wheels …………Rear.. 10″ x 15″ Revolution 5 spoke.. Front.. 3 1/2″ x 13″ split rim Revolution RFX

Tyres ……………Rear.. 295 50 15 BF Goodrich ( replaced original N50 x 15″ Kelly Supercharger ).. Front 135 70 13 Michelin

Steering ………..Narrowed Reliant Kitten Rack ( by Steve Phillips of DS Eng (see links)), upper part of column Fiat 131, middle CDS tube. Tubular track rods, spherically jointed track rod ends mounted in double shear brackets to strut.

Radiator ……….Opel Senator core, Rover SD1 end tanks, Marina top and bottom plates.

Fan ………………Fiat 132 electric.

Brakes …………Rear.. Ford Capri discs and calipers. Mintex M1144 pads.. Front.. Volvo discs and calipers… Twin master cylinders with balance bar (no servo). Reliant Kitten hand brake lever.

Propshaft ……..1310 series slip shaft made by me.

Interior …………Fire extinguisher, master cut off switch, overhead switch panel, B+M ratchet shifter, tachometer, Reliant Kitten speedo,
water temp. gauge, oil pressure gauge.

Performance ….With stock scrap yard engine 12.81 sec quarter mile. With new engine 0-100 mph 10 secs. No accurate quarter mile times available. ( I ran 13.41 secs with the new engine but the track was very poor and I was getting a lot of wheel spin in 1st and 2nd gear. On a good road surface I struggle to get ANY wheel spin.) Top speed 130 mph @ 6500rpm!



Reliant Kitten Pro-Street dans Pro-Street 0



2%2Bfront%2Bcut%2Boff dans Pro-Street



2%2Bstripping%2Bcar



4%2Brear%2Bsusp%2Bdesign



6%2Baxle%2Bbefore%2Bnarrowing



7%2Bmocking%2Bup%2Bfor%2Baxle%2Bwidth



8%2Bnarrowed%2Baxle



9%2Brear%2Bwheel%2Band%2Btyres



10%2Bcutting%2Bfront%2Bbody%2Bwork



11%2Bfront%2Bstrut



12%2Bover%2Bview%2Bof%2Bmock%2Bup



13%2Bdetail%2Bfront%2Bmock%2Bup



14%2Bengine%2Bbay%2Bmock%2Bup



15%2Bchassis%2Bbase



16%2Bdesign%2Bof%2Bcage



17%2Brear%2Bend%2Bupright



18%2Brear%2Bend%2Bbehind%2Bbody



19%2Bfront%2Bwheels



23%2Bbasic%2Bframe



24%2Bbody%2Bin%2Bstorage



25%2Bfurther%2Bconstruction



26%2Brear%2Bchassis



27%2Bframe%2Bwith%2Bwheels%2Bmocked



28%2Bframe%2Baround%2Bengine



30%2Btrial%2Bfit%2Bof%2Bbody



30e99cdb8d2c069df72cca1e6c00387a



31%2Bfront%2Bwheel%2Bin%2Bbody



32%2Bfinished%2Bbasic%2Bchassis



33%2Bgbox%2Bmount



34%2Bengine%2Bmount



35%2Bchassis%2Bround%2Brear%2Bof%2Bengine



36%2Bsteering%2Brack%2Bin%2Bposition



37%2Bbody%2Bmounted%2Bon%2Bchassis



38%2Bdoor%2Bhinge



39%2Bdoor%2Bhinge%2Bin%2Bdetail



41%2Brear%2Bbody%2Blower%2Bcut%2Boff



42%2Brear%2Bchassis



43%2Boverview%2Bof%2Bfront



44%2Brad%2Bin%2Bpos



45%2Bpedal%2Bbox



46%2Baxle%2Bin%2Bposition



47%2Bradius%2Barm%2Bbody%2Bmounts



48%2Bhand%2Bbrake%2Band%2Bradius%2Barm%2Bmounts



49%2Bfront%2Bbody%2Bwork%2Bfitting



51%2Binterior



54%2Bpanelling%2Brear



56%2Bview%2Bunder%2Brear



57%2Bpanels%2Bout%2Bof%2Bcar



58%2Bexhaust%2Bunder%2Bcar



59%2Bengine%2Bcoming%2Bout



60%2Bfinal%2Bwelding%2Bof%2Bchassis



63%2Binside%2Bof%2Bbody%2Bin%2Betch



64%2Binside%2Bof%2Bbody%2Bin%2Bblack



65%2Bfinished%2Bclean%2Bchassis



66%2Bchassis%2Bfront%2Bview



69%2Bpowder%2Bcoated%2Bchassis



70%2Bfirst%2Btime%2Bout%2Bof%2Bgarage



70a%2Bfirst%2Btime%2Bout%2Bof%2Bgarage%2Bno%2Bpanels



72%2Bbuild%2Bup



73%2Bbody%2Bprep



74%2Bbody%2Bsanding



75%2Bflatting%2Bprimer



76%2Bmore%2Bflatting



78%2Bfinal%2Bcolour



78a%2Brear%2B4%2Blink



78b%2Baxle



78c%2Brear%2Bbrakes



78d%2Bfront%2Bsusp



80%2Bmore%2Bwiring



81%2Belectrical%2Bpanel



83%2Badding%2Bwater



84%2Blifting%2Bfront%2Bover%2Bcar



86%2Btesting%2Blights



92%2Bexhausts%2Bon



95%2Binto%2Bstage%2Brun%2B2



96%2Brun2



100%2Banother%2Brun



100b%2BParked%2Bat%2BYork%2Bwith%2BRobin



104%2Bdirty%2Bunderneath



105%2Bfinished%2Bcar



107%2Bburnout



110%2Bengine%2Bback%2Bin



111%2Bnew%2Bcoilover%2Bmnts



112%2Bnew%2Bchassis%2Brear



113%2Bnew%2Brear%2Bchassis%2Bin



114%2Bpetrol%2Bdetails



115%2Bfuel%2Bpump%2Band%2Bsilencer



116%2Bexh%2B2%2Binto%2B1



117%2Bbattery%2Band%2Bsilencer



118%2Brear%2Bcaliper



120%2Bfinished%2Bpedal%2Bbox



121%2Bfront%2Bsusp



122%2Bpedal%2Bbox



123%2Boil%2Bcooler



C-LMXgsVoAAxXm-



side%2Bview

Image de prévisualisation YouTube
